MAP: 899.00
Features:
- Built-in MP3 Player Module with USB Jack
- Recording Function to USB Flash Drive
- 2 HDMI Inputs, 1 HDMI Output
- 2 Audio/Video Inputs: DVD/VOD
- 1 RCA Audio/Video Output
- Optical / Coaxial Inputs
- Audio Bluetooth Receiver Built-in For Streaming From Smart Devices
- Echo: Low, Mid, High, Repeat, Delay,Volume Controls
- Music : Low, Mid, High, Balance, Volume Controls
- Microphone: Echo, Balance, Low, Mid, High, Volume Controls for Individual microphones
- 3 XLR Front 2- 1/4" Microphone Inputs
- 2 XLR Back 2-1/4" Microphone Inputs
- Master Microphone Control
- Master Volume Control
- Line Output
- Recording Output
- Pre-Processing Output
- Sound Effect Input/ Output
- 2 Banana Plug Speaker Connectors
- 2 Speakon Plug Speaker Connectors
- Voltage: AC 115V - 230V Manual Select
- 110W AC Power Outlet
- Dimensions(W) x (H) x (D)
- Shipping Dimension: (W) x (H) x (D)
- Product Weight: lbs
- Shipping Weight: lbs.
Specifications:
- Power Output : 650W + 650W @ 8Ω (Peak)
- Power Output :250W + 250W @ 4Ω (RMS)
- Power Output :160W + 160W @ 8Ω (RMS)
- Music Input Sensitivity: 15mV
- External Devices Sensitivity : 250mV
- T.H.D : <0.1%
- Noise Ratio: 80dB
- Frequency Band : 25Hz ≈20kHz
- Mic Tone Adjustment:
80Hz +/- 15dB
3.5Hz +/- 8dB
12Hz +/- 15dB
Echo Tone Adjustment:
80Hz +/- 15dB
12Hz +/- 15dB
Instruction to connecting smart devices to the amplifier through Bluetooth
- Turn on Bluetooth on your phone
- Press “BT” button on the front panel of the amp and wait for your phone to search.
- Choose “Bluetooth Amp” on your phone and connect it.
- Now you are ready to stream music from your phone to the amp. Please note, Bluetooth will only send audio to the amp, graphic won’t get transferred
|
